<i>In-situ</i> liquid phase transmission electron microscope and its application in nanoparticle characterization

姓名
邮箱
手机号码
标题
留言内容
验证码

Abstract

Based on the improvement of transmission electron microscope (TEM), nano fabrication, and film deposition, and with the development of the in-situliquid TEM and nano characterization platform, various relevant nano researches have been carried in different fields. In this article, the principle, basic design requirements, development and typical preparation technologies of the liquid cell are briefly introduced. Subsequently, the state-of-the-art applications of liquid cell transmission electron microscope in the nucleation and growth of nanoparticles are reviewed. Finally, the opportunities and challenges faced by the frontier development of this technology are also discussed. This article provides constructive discussion about and support for advanced nano characterization technology and precise manipulation of atomic structures.

Keywords:

in situliquid transmission electron microscope/
nano characterization/
in situliquid cell

Authors and contacts

Corresponding author:Guo Hong-Xuan,ghx@seu.edu.cn; Sun Li-Tao,slt@seu.edu.cn

Funds:Project supported by the National Natural Science Foundation of China (Grant No. 11874105) and the National Science Fund for Distinguished Young Scholars of China (Grant No. 11525415)
