无磁光学非互易在量子通信、量子网络和光信息处理等方面具有重要的应用. 本文通过简并二能级热原子系统, 在单向泵浦场作用下, 考虑热原子的多普勒效应, 实现双路简并四波混频信号的非互易放大. 在此基础上, 再引入一束对向共线传播的泵浦场, 形成了空间复用的多重四波混频过程, 从而实现了双通道四波混频信号的互易放大. 进一步, 利用多组涡旋相位片分别对信号光和泵浦光加载螺旋相位, 产生携带光学轨道角动量的高阶拉盖尔-高斯涡旋光束, 并参与到四波混频过程中, 实现了泵浦光的轨道角动量向增益光场的转移; 同时利用马赫-曾德尔干涉仪, 进一步分析了各路四波混频信号场在非互易-互易放大转换下, 光学轨道角动量的守恒特性. 该结论为实现基于复杂结构光的光学非互易器件的应用研究提供了重要的参考.Magnet-free optical nonreciprocity has significant applications in quantum communication, quantum networks, and optical information processing. In this research, considering a degenerate two-level thermal atomic system with the Doppler effect of thermal atoms, the nonreciprocal amplification (NRA) of dual-path degenerate four-wave mixing (FWM) signals is achieved under the action of a co-propagating pumping field. On this basis, spatially multiplexed multiple FWM processes are formed by introducing another counter-propagating pumping field, thereby achieving the reciprocal amplification (RA) of the dual-channel FWM signals. Furthermore, by using multiple sets of spiral phase plates to load spiral phases on the signal light and the pumping light respectively, higher-order Laguerre-Gaussian vortex beams carrying different optical orbital angular momentum (OAM) are generated and participate in the FWM process, achieving the transfer of the OAM of the pumping light to the amplified FWM fields. Simultaneously, using the Mach-Zehnder interferometer, the conservation characteristics of the OAM of each FWM signal in the NRA-RA conversion are further analyzed. Furthermore, experimental results demonstrate that in the multiple FWM process induced by a pair of counter-propagating pump fields, the OAM of the amplified FWM signal in each channel varies with that of the pump field. However, the overall process maintains the OAM conservation. This study provides a feasible solution for expanding the channel capacity using OAM based on NRA-RA system, showing that the OAM has potential application prospects in achieving high-capacity optical communication and multi-channel signal processing.
-
Keywords:
- optical nonreciprocity /
- four-wave mixing /
- optical orbital angular momentum /
- vortex beam
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] [11] [12] [13] [14] [15] [16] [17] [18] [19] [20] [21] [22] [23] [24] [25] [26] [27] [28] [29] [30] [31] [32] [33] [34] [35] [36] [37] [38] [39] [40] [41] [42] [43] [44] [45] -
${l_{{{\text{S}}_1}}}$ ${l_{{{\text{C}}_{1}}}}$ ${l_{\rm S'_1}}$ ${l_{\rm C'_1}}$ ${l_{{{\text{S}}_{2}}}}$ ${l_{{{\text{C}}_2}}}$ ${l_{{{{\text{S}}}'_{2}}}}$ $ {l_{{{{\text{C}}}'_{2}}}} $ $\qquad{l_{{{\text{P}}_1}}} = - 1$, ${l_{{{\text{P}}_{2}}}} = 0$ 0 –2 1 –1 0 0 –1 –1 $\qquad{l_{{{\text{P}}_1}}} = - 1$, ${l_{{{\text{P}}_{2}}}} = - 1$ 0 –2 0 –2 0 –2 0 –2 $\qquad{l_{{{\text{P}}_1}}} = - 1$, ${l_{{{\text{P}}_{2}}}}{=}1$ 0 –2 2 0 0 2 –2 0 $\qquad{l_{{{\text{P}}_{1}}}} = - 1$, ${l_{{{\text{P}}_{2}}}} = - 2$ 0 –2 –1 –3 0 –4 1 –3 $\qquad{l_{{{\text{P}}_{1}}}} = - 1$, ${l_{{{\text{P}}_{2}}}} = 2$ 0 –2 3 1 0 4 –3 1 -
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] [11] [12] [13] [14] [15] [16] [17] [18] [19] [20] [21] [22] [23] [24] [25] [26] [27] [28] [29] [30] [31] [32] [33] [34] [35] [36] [37] [38] [39] [40] [41] [42] [43] [44] [45]
