寻找稳定高效的储氢材料是实现氢经济的关键. 过渡金属修饰石墨烯储氢材料在理论上被广泛研究, 但存在H 2解离和金属团聚的问题. 本文基于密度泛函理论对Sc, Ti, V修饰单缺陷石墨烯的结构及储氢性能进行计算. 结果表明: 单缺陷使Sc, Ti, V与石墨烯的结合能提高4—5倍; Sc, Ti, V离子特性增强, 可以通过静电相互作用吸附7, 3和4个分子形式的氢; 平均氢分子吸附能分别为–0.13,–0.20和–0.18 eV, 处于室温和中等压力下储氢的最佳能量范围. 而Sc, Ti, V修饰的完整石墨烯上第1个氢解离吸附, 氢分子吸附能分别为–1.34, –1.34和–1.16 eV. 特别重要的是, Sc, V修饰的缺陷石墨烯吸附和脱附氢分子过程中重构能仅为0.00 eV和0.03 eV, 对实现快速吸放氢气非常有利. 本研究将有利于深入认识3d过渡金属修饰碳材料的储氢机理.With the depletion of fossil fuels and the environmental problems, the development and utilization of new energy resources is imminent. Hydrogen energy is one of the main new energy sources in the 21st century. Finding stable and efficient hydrogen storage materials is the key to achieving the hydrogen economy. Transition metal (TM)-decorated graphenes have been widely studied as hydrogen storage materials theoretically, but they suffer metal agglomeration and H 2dissociation. Our calculations show that the reconstruction energy of Sc, Ti, V decorated pristine graphenes in the process of adsorption and desorption of hydrogen molecules are only 0.00, 0.12 and 0.08 eV, respectively. The adsorption energy values of the first H 2dissociation adsorption on the Sc, Ti, V decorated pristine graphenes are –1.34, –1.34, and –1.16 eV, respectively. So, some hydrogen molecules are difficult to desorb at room temperature and medium pressure. In this paper, the stability and hydrogen storage properties of Sc, Ti, V decorated monovacancy graphene are also investigated based on density functional theory. The results show that the binding energy values between Sc, Ti, V and themonovacancy graphene are –6.93, –8.82, –9.30 eV, respectively, which indicate monovacancy can effectively avoid metal aggregation. The Sc, Ti and V atoms decorated on the monovacancy graphene would transfer more electrons to the carbon material with charge of +1.24| e|–+1.37| e|. They can adsorb 7, 3 and 4 hydrogen molecules through electrostatic interaction. When a monovacancy is introduced, all of the hydrogen molecules are adsorbed in molecular form. The average adsorption energy values of H 2are –0.13, –0.20 and –0.18 eV, respectively, which are in the best energy range for the adsorption/desorption process at room temperature and medium pressure. The most important thing is that their deformations in the adsorption/desorption process are very small, which is conducive to the rapid hydrogen adsorption/desorption. The calculated results show that the monovacancy introduction can effectively solve the two major problems, i.e. metal agglomeration and hydrogen molecular dissociation during hydrogen storage on Sc, Ti, V decorated pristine graphenes. The research in this paper will be helpful to further understand the hydrogen storage mechanism of 3d TM-decorated carbon nanomaterials.
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] [11] [12] [13] [14] [15] [16] [17] [18] [19] [20] [21] [22] [23] [24] [25] [26] [27] [28] [29] [30] [31] [32] [33] [34] [35] [36] [37] [38] [39] [40] [41] [42] [43] [44] [45] -
System TM cohesive nenergy[37]
(eV/atom)Eb/eV dTM—C/Å d/Å Δz/Å Charge/|e| Sc/PG –3.90 –1.60 2.35—2.36 1.78 +1.09 Ti/PG –4.85 –1.81 2.12—2.37 1.63 +1.06 V/PG –5.31 –2.40 2.08—2.31 1.52 +1.05 Sc/MVG –3.90 –6.93 2.07—2.08 1.96 0.58 +1.37 Ti/MVG –4.85 –8.82 1.84—2.14 1.67 0.52 +1.37 V/MVG –5.31 –9.30 1.77—2.07 1.47 0.41 +1.24 Syestem Ea/eV ER/eV E1/eV Q/|e| System Ea/eV ER/eV E1/eV Q/|e| 1H2-Sc/MVG –0.16 0.00 –0.16 1.38 2H-Sc/MVG 1.91 2.55 –0.64 1.58 1H2-Ti/MVG –0.24 0.51 –0.75 1.37 1H2-V/MVG –0.31 0.03 –0.34 1.23 2H-V/MVG 0.45 1.28 –0.83 1.39 nH2-Sc/MVG Ec/eV Ea/eV 键长/Å H—H Sc—H n= 1 –0.16 –0.16 0.76 2.53—2.54 n= 2 –0.16 –0.16 0.75—0.76 2.42—2.58 n= 3 –0.20 –0.17 0.76—0.77 2.39—2.57 n= 4 –0.12 –0.16 0.75—0.76 2.45—2.96 n= 5 –0.08 –0.14 0.75—0.76 2.67—3.19 n= 6 –0.13 –0.14 0.75—0.76 2.67—3.68 n= 7 –0.09 –0.13 0.75—0.76 2.60—3.89 nH2-Ti/MVG Ec/eV Ea/eV 键长/Å H—H Ti—H n= 1 –0.24 –0.24 0.78 2.30—2.31 n= 2 –0.16 –0.20 0.75—0.78 2.14—2.32 n= 3 –0.20 –0.20 0.75—0.81 2.10—2.52 nH2-V/MVG Ec/eV Ea/eV 键长/Å H—H V—H n= 1 –0.31 –0.31 0.79 1.93—2.01 n= 2 –0.15 –0.24 0.76—0.82 2.07—2.18 n= 3 –0.10 –0.19 0.77—0.82 1.93—3.36 n= 4 –0.06 –0.18 0.75—0.86 2.14—4.03 -
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] [11] [12] [13] [14] [15] [16] [17] [18] [19] [20] [21] [22] [23] [24] [25] [26] [27] [28] [29] [30] [31] [32] [33] [34] [35] [36] [37] [38] [39] [40] [41] [42] [43] [44] [45]
